Versatile 300kw to 1000kw Ocean Power Generator Solutions3.

Energy Producers Ltd

Categories: Water Power

2026-04-05

$5700

Overview Projects

Did you like this Work? Please Share

Product Description

Generator power converter		DMGC300K	DMGC500K		DMGC1000K
Generator rated power		300KW	500KW		1000KW
Rated voltage of generator (AC)		400V/690V	400V/690V		400V/690V
Input voltage range (AC)		0–550V/0-800V	0–550V/0-800V		0–550V/0-800V
Rated output power (AC)		300KW	500KW		1000KW
MPPT MPPT Voltage range (AC)		250-500V/400-750V	250-500V/400-750V		250-500V/400-750V
Max. Input current (AC)		476A/276A	794A/460A		1588A/920A
Rated output current (AC)		433A/251A	722A/418A		1444A/837A
THD Current harmonic		<3%(At rated power)
Power factor		>0.99
Max. efficiency		96%
Electrical structure		Power frequency transformer
Allowable grid voltage range (AC)		220V/380V/440V/480V (Three-phase) ±20%
Allowable grid frequency range		50Hz/60Hz±10%
Automatic operation conditions		AC input and power grid meet the requirements, and the power converter operates automatically
Restart time after power failure		2min ( Adjustable)
General parameters
Function	Rectification, wind turbine curve setting, adjustable output power
Automatic protection	Reverse connection protection, short circuit protection, island effect protection, LVRT, overheat protection, overload protection, ground fault protection, lightning arrester, etc
Display	Touch screen
Monitoring content	Generator voltage, current, power, inverter output power, * cumulative power generation, * power generation at any time
Protection level	IP20(Indoor)IP65 (Outdoors)
Telematics	RS485/USB/GPRS/WIFI/Ethernet (Optional)
Environment	-10-50°C,<90% Operating amb. Temp. & Hum -10-50°C,<90% no condensation
Noise (1m)	<70dB
Refrigeration mode	Forced air cooling
size / weight		201010602000mm 1.5t	280012002000mm 2.5t	400012002000mm 4t

Specifications

th style=”border:1px solid #ccc;padding:10px;background:#f5f5f5;text-align:left;font-size:13px;font-weight:bold;” >[‘Customization:’, ‘Available’]

th style=”border:1px solid #ccc;padding:10px;background:#f5f5f5;text-align:left;font-size:13px;font-weight:bold;” >[‘Nature of Source Flow:’, ‘Active Inverter’]

th style=”border:1px solid #ccc;padding:10px;background:#f5f5f5;text-align:left;font-size:13px;font-weight:bold;” >[‘Certification:’, ‘ISO9001, CE’]

td style=”border:1px solid #ccc;padding:8px;font-size:12px;” >[‘Generatorxa0powerxa0converter’, ‘DMGC300K’, ‘DMGC500K’, ‘DMGC1000K’]

td style=”border:1px solid #ccc;padding:8px;font-size:12px;” >[‘Generator rated power’, ‘300KW’, ‘500KW’, ‘1000KW’]

td style=”border:1px solid #ccc;padding:8px;font-size:12px;” >[‘Rated voltage of generator (AC)’, ‘400V/690V’, ‘400V/690V’, ‘400V/690V’]

td style=”border:1px solid #ccc;padding:8px;font-size:12px;” >[‘Input voltage range (AC)’, ‘0-550V/0-800V’, ‘0-550V/0-800V’, ‘0-550V/0-800V’]

td style=”border:1px solid #ccc;padding:8px;font-size:12px;” >[‘Rated output powerxa0(AC)’, ‘300KW’, ‘500KW’, ‘1000KW’]

td style=”border:1px solid #ccc;padding:8px;font-size:12px;” >[‘MPPT MPPT Voltage rangexa0(AC)’, ‘250-500V/400-750V’, ‘250-500V/400-750V’, ‘250-500V/400-750V’]

td style=”border:1px solid #ccc;padding:8px;font-size:12px;” >[‘Max. Input currentxa0(AC)’, ‘476A/276A’, ‘794A/460A’, ‘1588A/920A’]

td style=”border:1px solid #ccc;padding:8px;font-size:12px;” >[‘Rated output currentxa0(AC)’, ‘433A/251A’, ‘722A/418A’, ‘1444A/837A’]

td style=”border:1px solid #ccc;padding:8px;font-size:12px;” >[‘THDxa0Current harmonic’, ‘<3%(At rated power)’]

td style=”border:1px solid #ccc;padding:8px;font-size:12px;” >[‘Power factor’, ‘>0.99’]

td style=”border:1px solid #ccc;padding:8px;font-size:12px;” >[‘Max. efficiency’, ‘96%’]

td style=”border:1px solid #ccc;padding:8px;font-size:12px;” >[‘Electrical structure’, ‘Power frequency transformer’]

td style=”border:1px solid #ccc;padding:8px;font-size:12px;” >[‘Allowable grid voltage range (AC)’, ‘220V/380V/440V/480Vxa0(Three-phase) ±20%’]

td style=”border:1px solid #ccc;padding:8px;font-size:12px;” >[‘Allowable grid frequency range’, ’50Hz/60Hz±10%’]

td style=”border:1px solid #ccc;padding:8px;font-size:12px;” >[‘Automatic operation conditions’, ‘AC input and power grid meet the requirements, and the power converter operates automatically’]

td style=”border:1px solid #ccc;padding:8px;font-size:12px;” >[‘Restart time after power failure’, ‘2min (xa0Adjustable)’]

td style=”border:1px solid #ccc;padding:8px;font-size:12px;” >[‘Function’, ‘Rectification, wind turbine curve setting,xa0adjustable output power’]

td style=”border:1px solid #ccc;padding:8px;font-size:12px;” >[‘Automatic protection’, ‘Reverse connection protection, short circuit protection, island effect protection,xa0LVRT,xa0overheat protection, overload protection, ground fault protection, lightning arrester,xa0etc’]

td style=”border:1px solid #ccc;padding:8px;font-size:12px;” >[‘Display’, ‘Touch screen’]

td style=”border:1px solid #ccc;padding:8px;font-size:12px;” >[‘Monitoring content’, ‘Generatorxa0voltage, current, power, inverter output power, * cumulative power generation, * power generation at any time’]

td style=”border:1px solid #ccc;padding:8px;font-size:12px;” >[‘Protection level’, ‘IP20(Indoor)IP65 (Outdoors)’]

td style=”border:1px solid #ccc;padding:8px;font-size:12px;” >[‘Telematics’, ‘RS485/USB/GPRS/WIFI/Ethernet (Optional)’]

td style=”border:1px solid #ccc;padding:8px;font-size:12px;” >[‘Environment’, ‘-10-50°C,<90%Operating amb. Temp. & Hum xa0-10-50°C,<90% no condensation’]

td style=”border:1px solid #ccc;padding:8px;font-size:12px;” >[‘Noise (1m)’, ‘<70dB’]

td style=”border:1px solid #ccc;padding:8px;font-size:12px;” >[‘Refrigeration mode’, ‘Forced air cooling’]

td style=”border:1px solid #ccc;padding:8px;font-size:12px;” >[‘ size / weight’, ‘2010*1060*2000mmxa0xa0xa0xa0xa0xa01.5t’, ‘2800*1200*2000mmxa0xa0xa0xa0xa0xa0xa02.5t’, ‘4000*1200*2000mmxa0xa0xa0xa0xa0xa0xa04t’]

Key Features

Manufacturer/Factory & Trading Company: Manufacturer/Factory & Trading Company
