700kva three-phase in and out variable frequency | Deming Power
MOQ: 1 Piece (MOQ) | Price: US$50,800.00-95,000.00
1 Piece
(MOQ)
- DEMING
Energy Producers Ltd
- Category
Categories: AC POWER SOURCE, Power Inverter
- Date
Overview Projects
MOQ: 1 Piece (MOQ) | Price: US$50,800.00-95,000.00
1 Piece
(MOQ)
Did you like this Work? Please Share
Product Specifications
| US$50,800.00-95,000.00 | 1 Piece
(MOQ) |
| Customization: | Available |
| Output Type: | Triple |
| Warranty: | 1 Year |
| Power type | Three phase in and three phase out |
| Capacity | 800KVA |
| Circuit mode | IGBT/SPWM |
| AC Input | Phase number |
| Input voltage range(Vac) | 380V±15% |
| Input frequency range(Hz) | 30-70 |
| AC output | Phase number |
| Wave form | Pure sine wave |
| Output Voltage(V) | Low 0-150V |
| Low 0-260V | High 0-520V |
| Output Voltage Accuracy(V) | ≤1% |
| Output frequency range(Hz) | 45-65 |
| Output Frequency Accuracy (Hz) | ≤0.01% |
| Output rated current(A) | Low 1110.4A |
| THD | ≤3% |
| Dynamic response time | 2ms |
| Power factor (PF) | 0.8 |
| Overload capacity | 110%,10min;200%,10s |
| Peak Coefficient (CF) | 3:1 |
| Efficiency | ≥90%(Resistive load 80%) |
| Display | Type |
| Communication | RS485/RS232/WIFI/GPRS |
| Environment | Insulation strength |
| Noise (1 m) | ≤55dB |
| Ambient temperature | -10ºC~+50ºC |
| Humidity | 0-90%(No condensation) |
| Altitude(m) | ≤2000m |
| Indicator light | Electricity, Inverter (Power Supply, Overvoltage, Undervoltage, Overcurrent, Overheat, LED Model Configuration) |
| Protection | Input connection, input under voltage, output over voltage , output over current , output overload , output short circuit , overheat |
| Cooling mode | Fan |
Detailed Specifications
| Power type | Three phase in and three phase out | ||
| Capacity | 800KVA | ||
| Circuit mode | IGBT/SPWM | ||
| AC Input | Phase number | Three-phase four-wire + ground wire | |
| Input voltage range(Vac) | 380V±15% | ||
<span style="font-siz
