Product Description

Technical parameters of off grid wind solar hybrid controller 3KW

Type 3KW-24Vdc 3KW-48Vdc 3KW-96Vdc
Wind turbine rated power 3KW 3KW 3KW
Wind turbine max. power 6KW 6KW 6KW
Solar panel 900W 900W 900W
Battery 24Vdc 48Vdc 96Vdc
Function Rectifier,charge, control
Display mode LCD
Display content Wind turbine voltage, wind turbine current, wind turbine power, solar panel voltage, solar panel current, solar panel power, battery voltage, charge current
PWM constant pressure voltage >28Vdc >56Vdc >110Vdc
3-phase load voltage of the wind turbine 29±1Vdc 58±1Vdc 116±2Vdc
Recovery charging voltage of the wind turbine 27±1Vdc 54±1Vdc 108±2Vdc
Stop charge voltage of solar panel 29±1Vdc 58±1Vdc 116±2Vdc
Recovery charging voltage of solar panel <28Vdc <56Vdc <110Vdc
Low-voltage of the battery 20±1Vdc 40±1Vdc 80±2Vdc
Self-provided connecting wire of the battery >30mm² >12mm² >6mm²
PWM fuse 125A 80A 32A
Charging fuse 160A 100A 50A
Work environment temperature -30-60°C
Relative humidity <90% No condensation
Noise(1m) <40dB
Degree of protection IP20(Indoor)
Cooling method Forced air cooling
*Communication interface (optional) RS485/USB/GPRS/Ethernet
*Temperature compensation(optional) -4mv/°C/2V,-35°C~+80°C,
Accuracy:±1°C
Size of the controller (mm) 655*480*320 575*430*320 575*430*320
Weight of the controller 27 Kg 21Kg 21Kg
Size of the load (mm) 495*460*320 495*460*320 495*460*320
Weight of the load 16Kg 16 Kg 16 Kg

Technical parameters of off grid wind solar hybrid controller 3KW

Type 3KW-120Vdc 3KW-220Vdc
Wind turbine rated power 3KW 3KW
Wind turbine max. power 6KW 6KW
*Solar panel power 900Wp 900Wp
Battery 120Vdc 220Vdc
Function Rectifier,charge, control, *DC output
Automatic protection function Over voltage protection, constant voltage charge, arrester
Manual function Manual brake
Display mode LCD+LED
Display content Wind turbine voltage, current, power; solar panel voltage, current, power; battery voltage, charge current
PWM constant pressure voltage >145Vdc >260Vdc
Wind turbine 3-phase dump load voltage 150±2Vdc 270±2Vdc
Wind turbine recharge voltage 138±2Vdc 245±2Vdc
*Solar control stop charging voltage 150±2Vdc 265±2Vdc
*Solar control recharge voltage <140Vdc <250Vdc
*Diesel generator starting voltage 100±2Vdc 180±2Vdc
*Diesel generator off voltage 135±2Vdc 245±2Vdc
Self-provided battery connecting wire >4mm² >2.5mm²
PWM fuse 32A 16A
*Solar fuse 10A 6A
Charging fuse 50A 25A
Work environment temperature -30-60°C
Relative humidity <90% No condensation
Noise (1m) <40dB
Degree of protection IP20(Indoor)IP65 (Outdoors)
Cooling method Forced air cooling
* Extral Control function (optional)  Yawing, variable pitch, mechanical brake, hydraulic brake, electromagnetism brake
*Communication interface (optional) RS485/USB/GPRS/WIFI/Ethernet
*Temperature compensation (optional) -4mv/°C/2V,-35°C~+80°C,Accuracy:±1°C
Controller Size (mm)  Weight (kg) 510*360*240            17Kg 510*360*240            17Kg
Dump load Size (mm)  Weight (kg) 400*410*250            13Kg 400*410*250            13Kg

Technical parameters of off grid wind solar hybrid controller 5KW

Type 5KW-48Vdc 5KW-120Vdc 5KW-240Vdc
Wind turbine rated power 5KW 5KW 5KW
Wind turbine max. power 10KW 10KW 10KW
* Solar panel power 1.5KWp 1.5KWp 1.5KWp
Battery 48Vdc 120Vdc 240Vdc
Function  Rectifier,charge, control, *DC output
Automatic protection function Over voltage protection, constant voltage charge, arrester
Manual function Manual brake
Display mode LCD+LED
Display content Wind turbine voltage, current, power; solar panel voltage, current, power; battery voltage, charge current
PWM constant pressure voltage…
