8–12 kW High Control Precision Hybrid Inverter Three-Phase Energy Storage Converter
- Inicio
- 8–12 kW High Control Precision Hybrid Inverter Three-Phase Energy Storage Converter
Proyectos generales
¿Te ha gustado esta obra? Compártelo
MOQ: 1 pieza
| Rated power range | 8–12 kW (model dependent) |
|---|---|
| Personalización: | Disponible |
| Weight: | 35kg |
| Garantía: | 5 años |
| Modelo | DMEP-8KS48P3 |
| Battery type | Lithium or lead acid battery |
| Rated battery voltage (V) | 48 |
| Maximum charging voltage (V) | ≤60(configurable) |
| Maximum charge/discharge current (A) | 190 |
| Maximum DC input power (kw) | 10.4 |
| Maximum DC input voltage (V) | 1000 |
| MPPT Operating voltage range (V) | 150~800 |
| Starting voltage (V) | 150 |
| Maximum input current (A) | 18/18 |
| MPPT number | 2 |
| Maximum output apparent power (W) | 8800 |
| Rated output voltage (V) | 400(±2%) |
| Rated output frequency (Hz) | 50/60(±0.2%) |
| Maximum output current (A) | 13.3 |
| Output power factor | ~1(-0.8 leading ~+0.8 lagging) |
| Rated output apparent power (VA) | 8000 |
| Maximum output apparent power (VA) | 16000,15sec |
| Maximum efficiency (PV) | 98% |
| Maximum efficiency (Battery) | 94.5% |
| Europe efficiency | 97.5% |
| DC reverse-polarity protection | Sí |
| Short circuit protection | Sí |
| Output over current protection | Sí |
| Output over voltage protection | Sí |
| Insulation resistance monitoring | Sí |
| Residual current detection | Sí |
| Surge protection | Sí |
| Grid monitoring | Sí |
| Islanding protection | Sí |
| Temperature protection | Sí |
| Integrated DC switch | Sí |
| Operating temperature (ºC) | -25~60 |
| Storage temperature (ºC) | -30~65 |
| Humedad relativa | 0~95% |
| Working altitude (m) | ≤4000 |
| Refrigeración | Refrigeración por aire |
| Noise (dB) | < 25 |
| Weight (kg) | 35 |
| Size (width × height × depth) (mm) | 475*683*256mm |
| Protection class | IP66 |
| Topología | HF Isolation (Battery Side) |
Typical Applications
Suitable for off-grid homes, small industrial sites, RVs, boats and remote installations where stable AC power is required from solar/wind generation sources. With a pure sine wave output, it safely powers sensitive electronics such as computers and medical equipment.
Installation & Selection Tips
Choose an inverter rating at least 20% above your maximum continuous load. Mount the unit in a dry, ventilated location. Use DC and AC breakers of appropriate rating. Contact Jinan Deming Power technical support for sizing assistance and OEM/ODM options.
