High Efficiency Pure Sine Wave AC240V/120V Split Phase Inverter 50kVA
- Home
- High Efficiency Pure Sine Wave AC240V/120V Split Phase Inverter 50kVA
High Efficiency Pure Sine Wave AC240V/120V Split Phase Inverter 50kVA
- DEMING
Energy Producers Ltd
- Category
Categories: Off Grid Power Inverter
- Date
2026-04-07
Overview Projects
Did you like this Work? Please Share
Price: US$6,500.00 1-9 Pieces US$6,300.00 10+ Pieces
MOQ: 1 Piece (MOQ)
Metallurgy, Mineral & Energy Solar & Renewable Energy Solar Inverter Pure Sine Wave Solar Inverter
| Customization: | Available |
|---|---|
| After-sales Service: | Yes |
| Warranty: | Yes |
| Type | NB220-50KSZ |
| DC input | Input rated voltage |
| Input rated current | 139A / 76A / 72.5A |
| Input DC voltage range | 180-300 |
| AC input(AC Bypass) | Allow input voltage range |
| Bypass transfer time | ≤4 ms |
| AC output | Rated capacity |
| Output rated power | 40KW |
| Output rated voltage and frequency | 220 VAC / 380 VAC / 400 VAC,50Hz / 60Hz |
| Output rated current | 139A / 76A / 72.5A |
| Output voltage accuracy | 220 VAC / 380 VAC / 400 VAC ± 2% |
| Output frequency accuracy | 50Hz / 60Hz ±0.05% |
| Waveform distortion (THD).(Linear load) | ≤3% |
| Dynamic response time(Load 0←→100%) | 5% |
| Power factor (PF) | 0.8 |
| Overload capacity | 120%,3 minutes,150%,10 second |
| Crest factor (CF) | 3:1 |
| Inverter efficiency | 90% |
| WorkingEnvironment | Dielectric strength |
| Noise (1m) | ≤50dB |
| Ambient temperature | -10℃~+50℃ |
| Humidity | 0~90%,No condensation |
| Altitude | ≤5000 m |
| Pure Sine Wave | Yes |
| Equipped with copper transformer | Yes |
| If solar charger available | Yes |
| AC Charger | Optional |
| Productionfunction | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermalprotection |
| Size(mm) | 760*1400*1600mm |
| Weight(kg) | 550kg |
