Price: US$5,900.00-12,800.00 1 Piece (MOQ)
MOQ: 1 Piece (MOQ)
Metallurgy, Mineral & Energy Solar & Renewable Energy Wind Inverter
| US$5,900.00-12,800.00 | 1 Piece
(MOQ) |
|---|---|
| Customization: | Available |
| Output Power: | 100kw |
| Battery Bank Voltage: | 480V/380V |
| Type | NB360-100KSZ |
| DC input | Input rated voltage |
| Input rated current | 278A / 152A / 145A |
| Input DC voltage allowing range | 320-496 VDC |
| AC Input(AC bypass) | Allow input voltage range |
| Bypass transfer time | ≤100 ms (Can be customized ≤ 4ms version) |
| AC output | Rated capacity |
| Output rated power | 80KW |
| Output rated voltage and frequency | 220 VAC / 380 VAC / 400 VAC ,50Hz / 60Hz |
| Output rated current | 278A / 152A / 145A |
| Output voltage accuracy | 220 VAC / 380 VAC / 400 VAC ± 1% |
| Output frequency accuracy | 50Hz / 60Hz ±0.05% |
| Wave Form | Pure sine wave (Isolation transformer) |
| THD. | ≤3% (Linear load) |
| Power factor (PF) | 0.8 |
| Overload capacity | 110%,3 minutes,150%,5 seconds |
| Crest factor (CF) | 3:1 |
| Inverter efficiency | 90% |
| Working Environment | Dielectric strength |
| Noise (1m) | ≤50dB |
| Ambient temperature | -10ºC~+50ºC |
| Humidity | 0~90%,No condensation |
| Altitude | <2000m(Higher than 2000m rated power should be reduced) |
| Production function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection |
| Pure Sine Wave | Yes |
| Equipped with copper transformer | Yes |
| Solar Charger | Optional |
| AC Charger | Optional |
| Generator Port | Optional, available |
| Size(mm) | Product Size: 650*1400*1500 |
| Weight(kg) | 730kg |
| Input DC voltage range | 300-465 VDC |
| AC input(AC Bypass) | Allow input voltage range |
| Waveform distortion (THD). (Linear load) |
≤3% |
| Dynamic response time (Load 0←→100%) |
2ms |
| If solar charger available | Yes |
| RS485 | Optional |
| Waveform distortion (THD).(Linear load) | ≤3% |
| Dynamic response time(Load 0←→100%) | 2ms |
| Generator port | Optional |
