off Grid Power Solar Inverter for Energy Storage System 20kw 30kw 50kw 100kw Three Phase Pure Sine Wave Output Power Supply
- Inicio
- off Grid Power Solar Inverter for Energy Storage System 20kw 30kw 50kw 100kw Three Phase Pure Sine Wave Output Power Supply
off Grid Power Solar Inverter for Energy Storage System 20kw 30kw 50kw 100kw Three Phase Pure Sine Wave Output Power Supply
- DEMING
Energy Producers Ltd
- Categoría
Categorías: Off Grid Power Inverter
- Fecha
2026-04-07
Proyectos generales
¿Te ha gustado esta obra? Compártelo
Price: US$3,200.00-9,999.00 1 Piece (MOQ)
MOQ: 1 Piece (MOQ)
Metallurgy, Mineral & Energy Solar & Renewable Energy Solar Inverter
| US$3,200.00-9,999.00 | 1 Piece
(MOQ) |
|---|---|
| Customization: | Available |
| After-sales Service: | Provide Warranty Service |
| Warranty: | Two Years |
| Operation mode | Continuous |
| AC wiring mode | Three phase four wire |
| Rated output power | 10KW |
| Output overload capacity | 11KW |
| Maximum DC power | 11KW |
| DC voltage range Vdc | 200-700Vdc |
| Recommended battery nominal voltage | 240V 384V 420V 480V |
| Rated charge current | 50A |
| Max input current | 55A |
| Voltage accuracy | ±1% |
| Steady flow accuracy | ±1% |
| DC current ripple | <1% IPP |
| Rated grid voltage(AC) | 220V / 380V / 440V |
| Grid voltage range | ±20% |
| Rated grid frequency | 50Hz / 60Hz |
| Grid frequency range | ±10% |
| Rated power(THD) | <3% (Standard grid) |
| Power factor | 0.8leading-1-0.8lagging, adjustable |
| Rated output voltage(AC) | 220V / 380V / 440V±1% |
| Output voltage distortion | <3% ( resistive load) |
| Rated output frequency | 50Hz / 60Hz ±1% |
| Voltage transition range | <10% (Resistance load 0% 100%) |
| On/off grid switching time | 0ms |
| Max. conversion efficiency | 97% |
| Noise | <60dB |
| Protection Degree | IP21 |
| Working Temperature | -25ºC~+45ºC |
| Cooling method | Air cooling |
| Working humidity | 0~95% |
| Working altitude | ≤6000m(Reduced usage for more than 2000m) |
| Emergency stop | Yes (via emergency stop button) |
| Display | Touch screen |
| Communication mode | RS485,WIFI,GPRS,Ethernet (Modbus protocol) |
| Dimensions | 690*275*770mm |
| Weight | 42KG |
